PORTKEYS LH5P 5.5 4K HDMI Touchscreen Monitor with Camera Control for BMPCCURSA MiniBMPCC 6K4K (ประกันศูนย์)

PORTKEYS LH5P 5.5″ 4K HDMI Touchscreen Monitor with Camera Control for BMPCC/URSA Mini/BMPCC 6K/4K

5.5 “HDMI 4K30 จอทัชสกรีน อินพุตและเอาต์พุต HDMI สูงสุด 4K30P ความสว่าง 1700 cd/m² แสดงตัวอย่าง HDR การควบคุมกล้องไร้สาย Sony A7MIII และ BMPCC 4K/6K/6K Pro ควบคุมฟังก์ชั่นของกล้อง เช่น REC, โฟกัส, ม่านตา และอื่นๆ รองรับ 3D LUT พร้อม LUT แบบกำหนดเองผ่าน USB

Portkeys LH5P Supported Camera Models

Sony:

Wireless Camera Control Sony A7MIII.

A9, A7C, A7M II, A7R II, A7S II, A7M III, A7R III, A7R IV, A6000, A6300, A6400, A6500, RX100, RX02 [MULTI control cable] FS5, FS7, FX6, FX9 [LANC control cable]

A7C, ZEV10 [USB-C control cable]

A7S III [Sony Multi control cable]

Canon:

5D MARK III, 5D MARK II, 6D, 6D MARK II, 80D [MINI USB control cable] 1DX, 1DX MARK II, 5DS, 5DS R, 5D MARK IV [MICRO USB control cable] R5, R6, EOS R [TYPE-C (USB-C) control cable)] C70, C700 PL, C700 GSPL, C300 MARK 2, C300 MARK 2 PL, C200, C200B, C100, C100 MARK 2 [LANC control cable]

Wired Motors Control TILTA Nucleus N/M and Cursor Display

NUCLEUS-N, NUCLEUS-M [Tilta NUCLEUS-N/M control cable]

Panasonic:

BGH1, BS1H, GH5 II, GH5S, GH5, S1, S1H, S1R, S5, G9 [TYPE-C (USB-C) control cable)]

Z CAM: E2, E2 S6, E2 F6 (LANC control cable)

REC key (LANC control cable)

BlackMagic: BMPCC4K, BMPCC6K(Bluetooth connection)

URSA MINI 4K, URSA MINI 4.6K, URSA MINI PRO 4.6K G2, URSA BROADCAST, CINERA CAMERA 2.7K, CINERA CAMERA 4K, MICRO STUDIO CAMERA 4K (LANC control cable)

Key Features

5.5″ LCD on-camera monitor that features 1700 cd/m² and a 1000:1 contrast ratio

HDMI input and output up to UHD 4K30 or DCI 4K24

Control camera functions such as REC, focus, iris, and more on a Blackmagic Design Pocket Cinema Camera, URSA Mini, or Pocket Cinema Camera 6K/4K via the camera control cable (see your camera manual for which functions can be accessed via the control port)

Control a Blackmagic Cinema Camera 6K or 4K via the built-in Bluetooth module

3D LUT support with custom LUTs via USB

Multi-touch touchscreen

Power with the built-in L-Series battery plate or power your camera with a separately available dummy battery using the DC output

Camera Control Compatibility

Blackmagic Design URSA Mini 4K, URSA Mini 4.6K, URSA Mini PRO 4.6K G2, URSA Broadcast, Cinema Camera 2.7K, Cinema Camera 4K, Micro Studio Camera 4K (LANC control cable)

Display Size	5.5″
Display Resolution	1920 x 1080
Maximum Brightness	1700 nit
Contrast Ratio	1000:1
Display Technology	WELD
Touchscreen	Yes
Bit-Depth	10 bit (8+2 FRC)
HDMI Input	Yes It supports a signal up to DCI 4K (4096×2160) at 24fps or HD video at up to 60fps.
HDMI Output	Yes: DCI 4K at 24fps or HD video at up to 60fps.
Headphone Jack	Yes: 3.5mm jack
3D LUT Support	Yes
Monitoring Tools	Yes
Powering	Sony NP-F Battery
Other Power Inputs	Yes: 5-pin aviation power input/output port.
Power Output	Yes: 7.4V 5-pin aviation power input/output port,
Camera Control	Yes
Image Calibration	Yes: In-factory calibrated and can be re-calibrated with an optional Xrite i1 Display Pro prob
Mounting Points	1 x 1/4-20″ at the bottom



Software Functions:

3D LUT, Waveform, New Peaking, Histogram, Guides, Zebra, Check Field, Grids, Audio Meters, Tint, Touch Capability, Backlight, Adjustable Fan, Zooming, Image Flip, OSD Flip, Cross Hair, Camera Control, False Color, Anamorphic…

In the Box

• PORTKEYS LH5P 5.5″ 4K HDMI Touchscreen Monitor with Camera Control for BMPCC/URSA Mini/BMPCC 6K/4K
• BMPCC/URSA Mini/BMPCC 6K/4K Camera Control Cable
• USB Flash Drive for Firmware/3D LUTs
• USB Type-C Cable
• 2 x Antenna
• Storage Box
